Carli Suspension 2019+ Ram 3500 Long Travel Air Bag System
SKU: CS-DLTB-19-4.25
0 in stock
Carli Suspension 2019+ Ram 3500 Long Travel Air Bag System
Carli 2019+ Ram 3500 long travel airbags are the perfect solution for customers looking to balance ride quality and hauling capability. These airbags make up for the loss of capacity that comes from a soft ride leaf pack, but are specifically designed to allow for full wheel travel and articulation unlike a normal airbag kit.
The tapered piston, folding sleeve bag will not interfere with the ride quality of your suspension when not inflated and the internal bump stop in the bag affords an operating range of 0 to 100 psi (bags are rated to 2,000lbs./ea. at 100psi), suitable for big 5th wheels, work trucks, campers, boats, bumper pull trailers and hauling.
The Airbags will cycle 12″ of travel and run an industry standard 1/4″ airline and can be plumbed into existing on-board air systems. Carli provides everything needed to install the airbags and set them up for manual fill. These airbags were designed to work in conjunction with Carli Full Progressive Leaf Springs to regain the lost payload capacity and create an adjustable solution for varying loads. These will work with add-a-packs as well, but are better suited to the full progressive leaf springs to provide the best unloaded ride and payload capacity.
Lastly, this kit includes all air fittings, schrader valves and 1/4″ airline to set the bags up for manual fill or to plumb the bags into your exiting compressor system.
Note: Carli long travel air bags will only work with rear lifts that level to a 3″ front lift. 1″-2″ of lift in the rear is recommended. These will not work on stock height trucks, 2014+ 2500 Rams or on factory auto leveling air Ram 2500/3500 trucks.
- Supports up to 12 inches of travel
- Compatible with 1″-2″ rear lift
- Restore factory payload to full progressive springs
- Includes 1/4″ airline, fittings and schrader valves
- Adjustable rear loaded height, 2,000lb capacity per bag at 100psi
- Fitment: 2019+ Ram 3500 4×4 with 4.25″ axle tube
